Fire Special Seal Gate Valves Of The Elastic Base Seat
GVS(F)-0050 GVS(F)-0065 GVS(F)-0080 GVS(F)-0100 GVS(F)-0125 GVS(F)-0150 GVS(F)-0200 GVS(F)-0250 GVS(F)-0300 GVS(F)-0350 GVS(F)-0400
消防专用弹性座封闸阀 Fire Special Seal Gate Valves Of The Elastic Base Seat
| 产品型号 Product model | 公称通径DN | D | D1 | N-Φd | L | H | Hmin | Hmax | |||
| 1.0MPa | 1.6MPa | 1.0MPa | 1.6MPa | 1.0MPa | 1.6MPa | (全开) | (全开) | ||||
| GVS(F)-0050 | 50 | 135 | 125 | 4-Φ19 | 178 | 340 | 322 | 374 | |||
| GVS(F)-0065 | 65 | 185 | 145 | 4-Φ19 | 190 | 370 | 332 | 398 | |||
| GVS(F)-0080 | 80 | 200 | 160 | 8-Φ19 | 203 | 410 | 350 | 429 | |||
| GVS(F)-0100 | 100 | 220 | 180 | 8-Φ19 | 229 | 450 | 420 | 524 | |||
| GVS(F)-0125 | 125 | 250 | 210 | 8-Φ19 | 254 | 180 | 581 | 721 | |||
| GVS(F)-0150 | 150 | 285 | 240 | 8-Φ23 | 267 | 550 | 581 | 736 | |||
| GVS(F)-0200 | 200 | 340 | 295 | 8-Φ23 | 12-Φ23 | 292 | 630 | 736 | 942 | ||
| GVS(F)-0250 | 250 | 405 | 350 | 355 | 12-Φ23 | 12-Φ28 | 330 | 750 | 882 | 1013 | |
| GVS(F)-0300 | 300 | 460 | 400 | 410 | 12-Φ23 | 12-Φ28 | 356 | 820 | 1009 | 1117 | |
| GVS(F)-0350 | 350 | 520 | 460 | 470 | 16-Φ23 | 16-Φ28 | 381 | 980 | 1300 | 1655 | |
| GVS(F)-0400 | 400 | 580 | 515 | 525 | 16-Φ28 | 16-Φ31 | 406 | 1010 | 1380 | 1805 | |
