Features

Ø = DIN 100 ~ DIN 400

Gauge: EN 558 Series 20; ISO 5752; API 609

Coupling flanges: DIN 2501 PN 2.5 / 6 / 10 / 16; ANSI B 16.5, class 150

Coupling flange surface design: DIN 2526, form A

Actuator coupling flange: EN ISO 5211 or DIN 5482

Valve identification: DIN EN 19

Leak test: EN 12 266-1, EN 12 266-2, A grade

Operating temperature: -20 °C ~ 90 °C (-4 °F ~ 194 °F)

Differential pressure: max. 2.5 bar (36.3 PSI)

Operating pressure: max. 2.5 bar (36.3 PSI)

Benefits

Few components

Interchangeable discs

Replaceable gasket

Highly abrasion-resistant

Easy to fit

Quick maintenance

Ex-stock delivery
