Bearing

32912 32913 32914 32915 32916 32917 32918 32919 32920 32922 32924 32926 32928 32930 32932 32934 32936 32938 32940 32944

Tapered Roller Bearings

PRODUCT DETAILS

32912 32913 32914 32915 32916 32917 32918 32919 32920 32922 32924 32926 32928 32930 32932 32934 32936 32938 32940 32944

model	d	D	B	Accuracy level	weight（kg）
32912	60	85	17	P0、P5、P4	0.306
32913	65	90	17	P0、P5、P4	0.323
32914	70	100	19	P0、P5、P4	0.494
32915	75	105	20	P0、P5、P4	0.53
32916	80	110	20	P0、P5、P4	0.56
32917	85	120	23	P0、P5、P4	0.8
32918	90	125	23	P0、P5、P4	0.841
32919	95	130	23	P0、P5、P4	0.877
32920	100	140	25	P0、P5、P4	1.18
32922	110	150	25	P0、P5、P4	1.29
32924	120	165	29	P0、P5、P4	1.8
32926	130	180	32	P0、P5、P4	2.25
32928	140	190	32	P0、P5、P4	2.39
32930	150	210	38	P0、P5、P4	3.81
32932	160	220	38	P0、P5、P4	4.06
32934	170	230	38	P0、P5、P4	4.3
32936	180	250	45	P0、P5、P4	6.65
32938	190	260	45	P0、P5、P4	7
32940	200	280	51	P0、P5、P4	9.5
32944	220	300	51	P0、P5	10.1

Tapered roller bearings are separable bearings, which are mainly used to bear combined radial and axial loads mainly based on radial loads. Compared with angular contact ball bearings, the bearing capacity is large and the limit speed is low. Tapered roller bearings can withstand axial loads in one direction and can limit the axial displacement of the shaft or housing in one direction.

The outer ring (or inner ring) of a double row tapered roller bearing is a single piece. The small end faces of the two inner rings (or outer rings) are similar, and there is a spacer in the middle, and the clearance is adjusted by the thickness of the spacer. The performance of the four-row tapered roller bearing is basically the same as that of the double-row tapered roller bearing, but it bears a larger radial load and a slightly lower limit speed than the double-row tapered roller bearing, and is mainly used for heavy machinery.

Brand: SKF, FAG, NSK, NTN, TIMKEN, CHY, Neutral, OEM

Accuracy: P0, P6, P5, P4

Material: GCr15

Cage: Steel
